most commonly used for joining rods and bolts
in bolted joints, it takes the form of a threaded ring with a thread cut along the entire length of the bore
frequently used in conjunction with DIN 976 rods or DIN 933 bolts, DIN 965 and DIN 931
used in a wide range of industrial sectors or for general domestic use
GLOTECH high-profile nut, m=3d, manufactured from A2 (stainless steel) or A4 (acid-resistant steel)
nut with metric thread
nuts with other technical specifications can be manufactured to order | Select | Catalogue | Index | ∅ M [mm] | Shape | Material grade | Other standard | Quantity per pack | U.m. |
|---|---|---|---|---|---|---|---|---|
| 10 | 6-kt | A2 - stal nierdzewna | DIN 6334 | 100 | opak. | |||
| 12 | 6-kt | A2 - stal nierdzewna | DIN 6334 | 50 | opak. | |||
| 16 | 6-kt | A2 - stal nierdzewna | DIN 6334 | 50 | opak. | |||
| 20 | 6-kt | A2 - stal nierdzewna | DIN 6334 | 10 | opak. | |||
| 6 | 6-kt | A2 - stal nierdzewna | DIN 6334 | 100 | opak. | |||
| 8 | 6-kt | A2 - stal nierdzewna | DIN 6334 | 100 | opak. | |||
| 24 | 6-kt | A4 - stal kwasoodporna | DIN 6334 | 10 | opak. |
